High Rate Max VRLA Battery

EverExceed High Rate MAX Range VRLA batteries provide high performance and reliability in fast discharge applications. Our development team combines the market's demand with design optimization, precision component selection and state of the art manufacturing process to produce the most cost effective battery solution for today's applications.
  • brand:

    EverExceed
  • Features
  • Technical datas
  • Successful case
  • Download

1) Plates: High Tin Pb alloy, optimized for high corrosion resistance.

2) Separator: Highly porous glass micro-fiber separator, optimized for low internal resistance, for maximum absorption of the electrolyte and for electrical separation of the positive and negative plates.

3) Standard housing: Reinforced special high temperature resistant  ABS  container and cover adopted.

4) Terminals: Silver plated copper female insert for easy and safe assembly and maintenance free connection with excellent conductivity.

5) Valves: Release gas in case of excess pressure and protects the cell against atmosphere.







Technical Features:


•   High density optimized positive plate design for maximum service float life - 15 years design life @ 20°C(68°F);
•   Nano-Carbon enhanced for improved durability;
•   Advanced corrosion resistant lead tin low calcium alloy, ensure the best performance for continuous operation up to 35°C;
•   Extreme temperature High-Compression Absorbed Glas Mat technology (AGM) for greater than 99% recombination efficiency;
•   Advanced triple stage unique terminal sealing design to ensure leak free operation, one way relief valve, explosion resistant;
•   Advanced deep cycle high tin lead alloy, reduces grid corrosion and promotes long battery life;
•   Heavy duty M6/M8 female copper plated terminals provide maximum performance and easy installation, reduce maintenance and increase safety;
•   Flame arresting, low pressure safety release venting system for individual cells;
•   Reinforced special high temperature resistant ABS container and cover adopted;
•   Wide operating temperature range: -40°C to +80°C;
•   Better high / low performance for outdoor applications, extended service life for non-temperature controlled outdoor enclosures.




Applications:


•   Uninterruptable power supply (UPS)
•   Switchgear
•   Emergency light
•   Overhead cranes
•   Telecom
•   Alarm and security
•   Industrial DC power


Battery Model Nom. Voltage (V) Capacity C10 1.80VPC 15 min. WPC 1.67 VPC Short Circuit Amps Internal Resistance Milliohms Terminal Type Battery Weight  Outline Dimensions (mm/inch)
kg lb Length Width  Height
HRM-1218 12 18 66.3 910 14 F-M5 5.7 12.5 181 7.13 76 2.99 167 6.58
HRM-1226 12 26 95.8 1315 10.3 F-M5 9.5 20.9 167 6.56 177 6.95 125.5 4.93
HRM-1233 12 33 122 1860 9.2 F-M6 10.8 23.7 195 7.68 130 5.12 180 7.07
HRM-1240 12 40 160 2250 8.5 F-M6 13.5 29.7 198 7.78 166 6.52 170 6.68
HRM-1255 12 55 203 2410 7 F-M6 17.5 38.5 229 9 138 5.41 215 8.46
HRM-1265 12 65 240 2670 6.3 F-M6 21.5 47.3 350 13.8 167 6.57 179 7.03
HRM-1270 12 70 280 2880 5.8 F-M6 23.5 51.7 260 10.2 168 6.62 215 8.46
HRM-1280 12 80 310 3200 5 F-M6 24.5 53.9 260 10.2 168 6.62 215 8.46
HRM-1290 12 90 325 3500 4.5 F-M6 28.5 62.7 305 12.1 168 6.64 215 8.46
HRM-12100 12 100 350 3500 4.2 F-M6 31 68.2 329 12.9 172 6.76 215 8.46
HRM-12120 12 120 430 4500 3.3 F-M6 36.5 80.3 407 16 175 6.9 225 8.86
HRM-12135 12 135 485 4600 3.1 F-M8 42.5 93.5 341 13.4 173 6.81 286 11.2
HRM-12150 12 150 506 5000 2.7 F-M8 45 99 483 19 170 6.7 240 9.47
HRM-12200 12 200 700 6000 2.4 F-M8 62 136 520 20.5 240 9.43 225 8.86
HRM-12230 12 230 800 6300 2.2 F-M8 65 143 520 20.5 269 10.6 210 8.26
HRM-12250 12 250 860 6600 2 F-M8 75 165 520 20.5 269 10.6 225 8.86



Project: UPS back up power

Country: Saudi Arabia

Year: 2016

Brief Description:

In 2016, EverExceed supplied High Rate Max batteries for UPS backup power solutions in Saudi Arabia.  We delivered two models HRM-1218 and HRM-1226 for this project. Our team helped installing 3000 cells of HRM- 1218 (12V 18Ah) and 1800 cells of HRM-1226 (12V 26Ah) to complete the projects.



If you need to download files, you need to register as our member first ! log in / registered

  • EverExceed High Rate Max Range VRLA - V2.1.pdf
