lndustrial Charger(DC UPS)

30VDC 10A uXcel mini Battery Charger

The industrial battery charger provides a advanced solution with Small substations and power plants system. Rectifier battery charger combines reliability from naturally cooled thyristor-based rectifier with proven microprocessor control technology to offer the best performances in any electrical and environmental conditions. It's suitable for charging VRLA sealed lead acid, Lithium battery as well as maintenance free nickel-cadmium batteries.

  • brand:

  • Features
  • Download

Technical features:

>Microcontroller based charger

>Touch screen display

>Manual and automatic switching
>Programmable float/boost charge change over

>Constant voltage and current limited

>Alarm and history event and download
>Very high reliability with thyristors and natural cooling

>Mains transformer with separate windings

>Mains input with contactor
>Battery inside cabinet optional

>Easy Maintenance

>Input and output MCB protection

Protection and alarm

• Overload/short circuit

• Input and output fuse or breaker

• Over temperature protection

• Over DC voltage/under DC voltage

• Ground alarm

• Dropping diode(optional)


• Mains on / Manual

• Run / Mains fault

• BAT MCB on / Load MCB on

• Float / Boost

• Ground fault

• Dropping diode(optional)


  • Power generation plants
  • Transmission and Distribution
  • Substations
  • Continuous process industries
  • Oil & Gas Petrochemical industries
  • Rail transport

Nominal input voltage

120/208/220/230/240VAC+10% ,Single phase (Other voltages can be customized)

Frequency 50/60Hz±5%
Output voltage 24V, 30V, 48V, 50V
Output voltage range 100%-150% nominal voltage
Output current 10A, 15A, 20A
Ripple voltage Within 5% RMS at full load&max.DC voltage
Current Limited to 110% of In
Output Regulation ±1% for 198 to 242VAC supply voltage
Analog measurements Output voltmeter and amperemeter,load voltmeter and amperemeter(Dropping diode type)
Local alarms Mains fault,output under voltage,output overvoltage,ground fault
Mode of operation Boost/float, Manual/Automatic
Protections Overload/short circuit,Charger fuses,Battery and load breaker,Over temperature protection
Available languages English,Spanish(Optional)
Cabinet Dimession
Battery inside cabinet:1100H*580W*600D
Battery outside cabinet:350H*440W*500D
Degree of protection IP20
Color RAL7035
Operating Temperature 0℃ to 45℃,Up to 55℃ with power derating
Humidity 10% to 95% non condensing
Installation height Up to 1000m over sea level. Up to 3000m with power derating
Connection Bottom
Communication RJ45,Modbus TCP/IP
RS485,Modbus RTU
Volt-free contacts
Remote monitoring

If you need to download files, you need to register as our member first ! log in / registered

  • EverExceed Smart charger V1.0.pdf
