NiCd Battery

EBL Pocket Plate Range NiCd Battery

EverExceed pocket type nickel cadmium battery has been supplied stable and reliable battery solution for many industrial power applications. Our block batteries function in a wide range of temperatures, resist electrical abuse, shock and vibrations and need only basic maintenance. This ensures a low total cost of ownership (TCO) over a life cycle that can last 20 years or more.

  • brand:

    EverExceed
  • Certificates:

    ISO / TUV/CE/ IEC
  • Features
  • TECHNICAL DATA
  • SUCCESSFUL CASES
  • Download



①Protective cover
To prevent external short-circuits;

In line with EN50272-2(safety) with ip2 level;


②Plate groups bus
Connects the plate tabs with the terminal post;

Plate tabs and terminal post are projection-welded to the plate groups bus;


③Plate

Horizontal pockets of double-perforated steel stirps;


④Cell container

Material:translucent transparent polypropylene;


⑤Flame-arresting vents

Material: polypropylene;


⑥Plate tab

Spot-welded both to the plate side-frames and to the upper edge of the pocket plate;


⑦Separating grids
These separate the plates and insulate the plate rames from each other;

The grids allow free circulation of electrolyte between the plates;


⑧Plate frame
Seals the plate pockets and serves as a current collector.





Technical Features:


• Wide operating temperature range;
• Resistance to mechanical and electrical abuse;
• Low internal resistance;
• Absolute reliability;
• 20 years design life;
• The discharge time for 3h to 100h;
• Designed for applications where the battery is required to provide:
  -a reliable source of energy over relatively long discharge periods
  -a current that is relatively low in comparison with the total stored energy

  -discharges are generally infrequent




Our advantages:


• ISO 9001:2015/GB/T19001-2016  quality management system certificate;

• ISO 14001:2015/ GB/T24001:2016  environment management certificate;

• OHSAS 18001:2007/ GB/T28001:2011/  IDT occupational health and safety management system certificate;

• TUV Rheinland IEC60623: 2001 product type approval certificate;

• EverExceed battery is the qualified manufacturer approved by Huawei Technologies Co., Ltd.





Applications:


• Telecommunication, back-up power, railway lighting power and other emergency back-up power supplies.

Cell Type Nominal Voltage (V) Capacity (C5 Ah) Dimensions (mm/inch) Weight (kg/lb.) Terminal Cell Case Material
Length Width Height Without Electrolyte With Electrolyte
EBL10 1.2 10 40 1.6 85 3.3 150 5.9 0.7 1.5 1.0 2.2 M8 PP
EBL20 1.2 20 55 2.2 134 5.3 270 10.6 1.1 2.4 1.8 4.0 M10 PP
EBL30 1.2 30 55 2.2 134 5.3 270 10.6 1.5 3.3 2.2 4.8 M10 PP
EBL40 1.2 40 55 2.2 134 5.3 270 10.6 1.8 4.0 2.6 5.7 M10 PP
EBL50 1.2 50 60 2.4 140 5.5 270 10.6 2.4 5.3 3.2 7.1 M10 PP
EBL60 1.2 60 60 2.4 140 5.5 270 10.6 2.8 6.2 3.8 8.4 M10 PP
EBL70 1.2 70 70 2.8 141 5.6 295 11.6 2.9 6.4 4.1 9.0 M10 PP
EBL80 1.2 80 70 2.8 141 5.6 295 11.6 3.4 7.5 4.6 10.1 M10 PP
EBL90 1.2 90 80 3.1 140 5.5 365 14.4 4.2 9.3 6.0 13.2 M10 PP
EBL100 1.2 100 80 3.1 140 5.5 365 14.4 4.5 9.9 6.2 13.7 M10 PP
EBL120 1.2 120 80 3.1 140 5.5 365 14.4 5.0 11.0 6.5 14.3 M10 PP
EBL150 1.2 150 105 4.1 165 6.5 345 13.6 6.9 15.2 9.5 20.9 M20 PP
EBL200 1.2 200 105 4.1 165 6.5 345 13.6 7.8 17.2 10.0 22.0 M20 PP
EBL250 1.2 250 165 6.5 167 6.6 345 13.6 10.2 22.5 14.2 31.3 M20 PP
EBL300 1.2 300 140 5.5 280 11.0 450 17.7 13.8 30.4 21.0 46.3 2 x M16 PP
EBL350 1.2 350 140 5.5 280 11.0 450 17.7 15.0 33.1 22.0 48.5 2 x M16 PP
EBL400 1.2 400 140 5.5 280 11.0 450 17.7 15.8 34.8 22.8 50.3 2 x M16 PP
EBL500 1.2 500 140 5.5 280 11.0 490 19.3 16.8 37.0 24.0 52.9 2 x M20 PP
EBL355 1.2 355 140 5.5 280 11.0 444 17.5 14.3 31,4 20.5 45.1 2 x M16 PP
BEL390 1.2 390 140 5.5 280 11.0 440 17.3 14.9 33 21.8 47.9 2 x M16 PP
EBL600 1.2 600 175 6.9 290 11.4 500 19.7 27.0 59.5 37.0 81.5 2 x M20 ABS
EBL700 1.2 700 175/175 6.9/6.9 290/285 11.4/11.2 500/490 19.7/19.3 29.0/26.5 63.9/58.3 39.0/36.5 86.0/80.3 2 x M20 ABS
EBL695 1.2 695 170 6.7 285 11.2 490 19.3 26.2 57.6 36.4 80.0 2 x M20 ABS
EBL800 1.2 800 186 7.3 398 15.7 565 22.2 39.0 86.0 58.0 128 3 x M20 ABS
EBL900 1.2 900 186 7.3 398 15.7 565 22.2 41.0 90.4 60.0 132 3 x M20 ABS
EBL1000 1.2 1000 186 7.3 398 15.7 565 22.2 44.0 97.0 61.0 134 3 x M20 ABS
EBL1010 1.2 1010 186 7.3 398 15.7 565 22.0 39.8 88 56.1 123 3 x M20 ABS
EBL1100 1.2 1100 186 7.3 398 15.7 565 22.2 45.0 99.2 62.0 137 3 x M20 ABS
EBL1200 1.2 1200 186 7.3 398 15.7 565 22.2 46.0 101 63.0 139 3 x M20 ABS



Project name: Maibarara Geothermal Plant

Country: Philippines

Year: 2013


In 2013, EverExceed successfully finished the battery bank installation project for Maibarara Geothermal Plant in Philippines. During this project, EverExceed supplied them 500 cells of EBL200 (1.2V/200Ah)Ah and more than 100 cells of EBL1210 (1.2V/1210Ah) nickel cadmium batteries for the backup power system with high quality and reliability.






Project name: Mali substation

Country: Africa

Year: 2015

In May, 2015, EverExceed successfully finished the nickel cadmium battery installation for Mali substation project in Africa. During this project, we supplied them more than 600 cells EBL340 (1.2V/340Ah) and 266 cells EBL230 (1.2V/230Ah) nickel cadmium batteries. After commissioning, batteries performed well with good recognition from our customers.




Project name: Electricity Company

Country: Saudi Arabia

Year: 2012

In January, 2012, EverExceed supplied around 1084 cells of EBL 300Ah nickel cadmium batteries   ( 48V & 125V DC)to Saudi Arabia Electricity Company , which are featured for trouble-free long cycle life, low overall cost, easy storage and installation, assured reliability and optimized performance.




Project name: National Electric Power Company

Country: Jordan

Year: 2011

In May, 2011, EverExceed got opportunities to cooperate with NEPCO(National Electric Power Company) to supply them around 880 cells of EBL 100Ah (1.2V/100ah) Nickel Cadmium batteries, which generally operates between temperatures of -40℃ to +60℃ and can tolerate extremes of -50℃ to + 70℃ for short periods.



Project name: Oil transit line

Country: Kuwait

Year: 2011

In April, 2011, EverExceed successfully won the bid for EBL series Nickel cadmium battery installation project in Oil transit line back up power in Kuwait. We installed total 78,025 cells in four different projects. Until December 5, 2013, all the projects have been completed successfully. After commissioning successfully our batteries achieved good reputation and performance.
