At the heart of the system lies a high-density 314Ah LiFePO₄ cell, engineered to deliver exceptional longevity and reliable power for critical backup applications.
EverExceed delivers advanced high-voltage UPS lithium battery solutions featuring 51.2V 314Ah (14.34kWh) LiFePO₄ battery modules with over 8,000 cycles of lifespan. Each system provides up to 160kWh capacity. Equipped with comprehensive protection functions — including short circuit, over current, over/under voltage, and temperature safeguards — our high-voltage UPS lithium battery systems ensure safety, reliability, and powerful performance for critical power backup. As a trusted provider of industrial power solutions, EverExceed helps businesses achieve operational resilience, lower total cost of ownership, and truly uninterrupted power supply.
brand:
EverExceedModel:
ES512-314N/ ES384-314NRated voltage(V):
512V/ 384VRated capacity(Ah):
314AhCertificates:
UN 38.3; CEOEM/ODM Service:
Yes, customized service availableUsage:
UPS / Data Center
At the heart of the system lies a high-density 314Ah LiFePO₄ cell, engineered to deliver exceptional longevity and reliable power for critical backup applications.
| Basic Specification | ||
| Nominal Voltage | 512V(±256V) | 384V(±192V) |
| Nominal Capacity | 314Ah | 314Ah |
| Energy | 160.7kWh | 120.5kWh |
| Charging | ||
| Maximum Charging Voltage | 552V | 414V |
| Maximum Charging Current | 150A | 150A |
| Discharging | ||
| Voltage Range | 448V~552V | 336V~414V |
| Maximum Continuous Discharging Current | 150A | 150A |
| Cut-off Voltage | 446V~464V | 336V~348V |
| Battery Module | ||
| Nominal Voltage | 51.2V | 48V |
| Nominal Capacity | 314Ah | 314Ah |
| Quantity | 10 | 8 |
| Others | ||
| Fire Protection | Battery module-level and Cabinet-level | |
| Protection | Over temperature, Over current, Short circuit, Over charge/discharge, etc. | |
| Communication Interface | CAN, RS485, Dry contacts | |
| Temperature | Charging: 0~45°C, Discharging: -20°C~60°C | |
| Dimension (W*D*H) | 1200*1000*1800mm | 1200*1000*1600mm |
| Weight | 1550±150KG | 1280±120KG |
 |
 |
 |
 |
If you need to download files, you need to register as our member first ! log in / registered
What is the difference in charging time?
Faster charging times are beneficial if you need backup power to be restored quickly. EverExceed UPS lithium battery fully meets the needs of use.
How do the lifespan and cycle life compare?
These factors will impact the long-term maintenance and replacement costs.
What are the differences in physical size and weight?
Understand the dimensions and weight of each UPS system to ensure it can be accommodated in your available space. Consider if you need a compact and lightweight solution or if you have ample room for a larger unit.
What are the safety considerations?
Inquire about the safety mechanisms and protections incorporated into each UPS system to prevent issues such as overcharging, short circuits and thermal events. This is crucial for the reliable and secure operation of the UPS.
How do your equipment requirements align with each UPS?
Ensure that the UPS type is compatible with the power requirements, voltage compatibility, and interfaces of your existing equipment.
What type of support is needed for each battery technology?
Understand the level of technical support and maintenance services offered for each battery type and ensure that you can obtain reliable support throughout the lifespan of the UPS.
