EverExceed high voltage LiFePO4 (lithium iron phosphate) battery is a new environment-friendly backup power module specially designed for UPS power systems. With an advanced life span, extra compact size, very lightweight, and strong environmental working conditions, besides indoor, it is also the ideal solution for the outdoor harsh environment found in the field, where the UPS are installed and used.
brand:
EverExceedModel:
ES192-314Rated voltage(V):
192VRated capacity(Ah):
314AhCertificates:
UN 38.3; CEOEM/ODM Service:
Yes, customized service availableUsage:
UPS/ Data Center
Four-layer safety protection with LiFePO4 cells, smart BMS, and dual built-in fire extinguishers ensures ultimate home energy safety.
Delivers ultra-fast 8C discharge, wide UPS compatibility, and long backup time with Grade A LiFePO4 cells for high reliability and performance.
The LiFePO₄ UPS battery offers up to 5000 cycles and a 15-year lifespan, delivers 70% space savings compared with lead-acid batteries, and features a smart BMS that significantly reduces routine O&M costs.
| Basic Specification | |
| Nominal Voltage | 192V |
| Nominal Capacity | 314Ah |
| Energy | 60.2kWh |
| Charging | |
| Maximum Charging Voltage | 207V |
| Maximum Charging Current | 150A |
| Discharging | |
| Voltage Range | 168V~207V |
| Maximum Continuous Discharging Current | 150A |
| Cut-off Voltage | 168V~174V |
| Battery Module | |
| Nominal Voltage | 48V |
| Nominal Capacity | 314Ah |
| Quantity | 4 |
| Others | |
| Fire Protection | Battery module-level and Cabinet-level |
| Protection | Over temperature, Over current, Short circuit, Over charge/discharge, etc. |
| Communication Interface | CAN, RS485, Dry contacts |
| Temperature | Charging: 0~45°C, Discharging: -20°C~60°C |
| Dimension (W*D*H) | 600*1000*1600mm |
| Weight | 720±70KG |
 |
 |
 |
 |
 |
 |
If you need to download files, you need to register as our member first ! log in / registered
What is the difference in charging time?
Faster charging times are beneficial if you need backup power to be restored quickly. EverExceed UPS lithium battery fully meets the needs of use
How do the lifespan and cycle life compare?
These factors will impact the long-term maintenance and replacement costs.
What are the differences in physical size and weight?
Understand the dimensions and weight of each UPS system to ensure it can be accommodated in your available space. Consider if you need a compact and lightweight solution or if you have ample room for a larger unit.
What are the safety considerations?
Inquire about the safety mechanisms and protections incorporated into each UPS system to prevent issues such as overcharging, short circuits and thermal events. This is crucial for the reliable and secure operation of the UPS.
How do your equipment requirements align with each UPS?
Ensure that the UPS type is compatible with the power requirements, voltage compatibility, and interfaces of your existing equipment.
What type of support is needed for each battery technology?
Understand the level of technical support and maintenance services offered for each battery type and ensure that you can obtain reliable support throughout the lifespan of the UPS.
