1.2V rechargeable maintenance free nicd battery

EBL Pocket Plate Range NiCd Battery

EverExceed pocket type nickel cadmium battery has been supplied stable and reliable battery solution for many industrial power applications. Our block batteries function in a wide range of temperatures, resist electrical abuse, shock and vibrations and need only basic maintenance. This ensures a low total cost of ownership (TCO) over a life cycle that can last 20 years or more.

brand:
EverExceed
Model:
EBL Series
Rated Voltage(V):
1.2V
Rated Capacity(Ah):
10Ah-1300Ah
OEM/ODM Service:
Yes, customized
Certificates:
TUV;IEC;ROHS;DEKRA
Usage:
Railway DC power supply, UPS switch transition

inquiry now

Easy to install and highly durable: NiCd batteries offer excellent resistance to mechanical and electrical abuse, ensuring long-lasting performance in demanding conditions.

Reliable High-Temperature Performance: NiCd batteries maintain stable performance even in high-temperature environments, making them ideal for devices that need to operate under heat stress, ensuring long-term reliability with fewer failures.

①Protective cover
To prevent external short-circuits；

In line with EN50272-2(safety) with ip2 level；

②Plate groups bus
Connects the plate tabs with the terminal post；

Plate tabs and terminal post are projection-welded to the plate groups bus；

③Plate

Horizontal pockets of double-perforated steel stirps；

④Cell container

Material:translucent transparent polypropylene；

⑤Flame-arresting vents

Material: polypropylene；

⑥Plate tab

Spot-welded both to the plate side-frames and to the upper edge of the pocket plate；

⑦Separating grids
These separate the plates and insulate the plate rames from each other；

The grids allow free circulation of electrolyte between the plates；

⑧Plate frame
Seals the plate pockets and serves as a current collector.

Applications:

• Railway DC power supply, UPS switch transition

Cell Type	Nominal Voltage (V)	Capacity (C5 Ah)	Dimensions (mm/inch)						Weight (kg/lb.)				Terminal	Cell Case Material
Cell Type	Nominal Voltage (V)	Capacity (C5 Ah)	Length		Width		Height		Without Electrolyte		With Electrolyte		Terminal	Cell Case Material
EBL10	1.2	10	40	1.6	85	3.3	150	5.9	0.7	1.5	1.0	2.2	M8	PP
EBL20	1.2	20	55	2.2	134	5.3	270	10.6	1.1	2.4	1.8	4.0	M10	PP
EBL30	1.2	30	55	2.2	134	5.3	270	10.6	1.5	3.3	2.2	4.8	M10	PP
EBL40	1.2	40	55	2.2	134	5.3	270	10.6	1.8	4.0	2.6	5.7	M10	PP
EBL50	1.2	50	60	2.4	140	5.5	270	10.6	2.4	5.3	3.2	7.1	M10	PP
EBL60	1.2	60	60	2.4	140	5.5	270	10.6	2.8	6.2	3.8	8.4	M10	PP
EBL70	1.2	70	70	2.8	141	5.6	295	11.6	2.9	6.4	4.1	9.0	M10	PP
EBL80	1.2	80	70	2.8	141	5.6	295	11.6	3.4	7.5	4.6	10.1	M10	PP
EBL90	1.2	90	80	3.1	140	5.5	365	14.4	4.2	9.3	6.0	13.2	M10	PP
EBL100	1.2	100	80	3.1	140	5.5	365	14.4	4.5	9.9	6.2	13.7	M10	PP
EBL120	1.2	120	80	3.1	140	5.5	365	14.4	5.0	11.0	6.5	14.3	M10	PP
EBL150	1.2	150	105	4.1	165	6.5	345	13.6	6.9	15.2	9.5	20.9	M20	PP
EBL200	1.2	200	105	4.1	165	6.5	345	13.6	7.8	17.2	10.0	22.0	M20	PP
EBL250	1.2	250	165	6.5	167	6.6	345	13.6	10.2	22.5	14.2	31.3	M20	PP
EBL300	1.2	300	140	5.5	280	11.0	450	17.7	13.8	30.4	21.0	46.3	2 x M16	PP
EBL350	1.2	350	140	5.5	280	11.0	450	17.7	15.0	33.1	22.0	48.5	2 x M16	PP
EBL400	1.2	400	140	5.5	280	11.0	450	17.7	15.8	34.8	22.8	50.3	2 x M16	PP
EBL500	1.2	500	140	5.5	280	11.0	490	19.3	16.8	37.0	24.0	52.9	2 x M20	PP
EBL600	1.2	600	175	6.9	290	11.4	500	19.7	27.0	59.5	37.0	81.5	2 x M20	ABS
EBL700	1.2	700	175	6.9	290	11.4	500	19.7	29.0	63.9	39.0	86.0	2 x M20	ABS
EBL800	1.2	800	186	7.3	398	15.7	565	22.2	39.0	86.0	58.0	128	3 x M20	ABS
EBL900	1.2	900	186	7.3	398	15.7	565	22.2	41.0	90.4	60.0	132	3 x M20	ABS
EBL1000	1.2	1000	186	7.3	398	15.7	565	22.2	44.0	97.0	61.0	134	3 x M20	ABS
EBL1100	1.2	1100	186	7.3	398	15.7	565	22.2	45.0	99.2	62.0	137	3 x M20	ABS
EBL1200	1.2	1200	186	7.3	398	15.7	565	22.2	46.0	101	63.0	139	3 x M20	ABS
