CRITICAL POWER

Hot-swappable Module Embedded Rectifier System

ER series adopts 19-inch rack disk redundant design, which is convenient for flexible expansion and provides enough power to meet the requirements of communication systems. It is suitable for power grids such as switches, computer rooms, base stations, satellite communications, data communications, railways and power systems for occasions with a wide fluctuation range, the operation is simple and convenient, and it is easy to install and maintain.
  • brand:

    EverExceed
  • Nominal DC voltage(Output):

    48VDC/24VDC
  • Nominal DC current(output):

    30A/50A/60A
  • Input AC voltage:

    220Vac/110Vac
  • Communication:

    RS485,SNMP
  • OEM/ODM Service:

    Yes, customized service available
  • Certificates:

    CE, EN61000, IEC60146
  • Applications:

    Widely used in communication and industrial fields.
  • Features
  • TECHNICAL DATA
  • SUCCESSFUL CASES
  • Download
  • Related documents
  • Video
  • FAQ

Technical features:


>Wide input AC voltage range: 90~290 Vac;

>Provide 6 sets of passive dry contacts;
>Power factor values up to 0.99;
>With battery management system, with battery temperature probe;
>Standard 19-inch 2U frame for easy cabinet installation;
>With activity alarm, sound and light form to remind alarm information;
>Have rich LED+LCD status display, alarm signal display and alarm recording functions;
>Ultra-lowradiation: using adyanced electromagnetic compatibility design;

>Efficiency of the whole machine: 93.2%;
>48V single module output current 50A/30A optional, 24V single module output current 60A, 2U system output current up to 150A, overall current up to 600A;

>Temperature compensation system, which can be set to protect once power off and two times power off;

>The system configuration is flexible, convenient and easy to expand. Various power systems can be configured according to the customer needs;


System Schematic:

Applications:


Widely used in communication and industrial fields. All of its communication power technology converts alternating current to direct current to supply power to the DC load, connects the battery pack in the power system to charge the battery pack, and detects the battery pack status. Three hot-swappable rectifier module ports can form an N+1 redundant system to provide fault tolerance for the load. In order to adapt to different external power supply systems, the monitoring system is equipped with 45 different alarm options. The monitoring screen can display current alarm information, query historical alarm information, and support RS485/SNMP remote operation.


Factoty


Model ER4830 ER4850 ER2460
AC input Voltage Single phase 220Vac/110Vac
frequency 50/60Hz (45-66Hz)
voltage range 185-290Vac
Rated voltage 48VDC 24VDC
float voltage 53.5VDC (42-58V) 26.7VDC (21-29V)
Equalizing voltage 56.4VDC (42-58V) 28.2VDC (21-29V)
power factor >0.99@220VAC
DC output efficient >92%@220VAC peak: >93.2%@220VAC 100% load
output precision ≤0.6%
leakage current <10mA
Output current 30A 50A 60A
RS485 Default (Modus RTU)
Communication TCP/IP default
Interface SNMP card Optional
dry contact 6 groups of DI, 6 groups of DO
LCD display Input/output voltage, frequency, output current, ambient temperature, load
Instruction power state Mains/Output/Undervoltage@Voltage     Overload
input Output RMS 3000Vac 50Hz or equivalent 4240VDC 1 minute ≤ 1mA
Isolation voltage Input - Chassis RMS 1500Vac 50Hz or equivalent 2120VDC 1 minute ≤ 1mA
Output - Chassis RMS 500Vac 50Hz or equivalent 710VDC 1 minute ≤ 1mA
Insulation resistance @Normal atmospheric pressure, 90% relative humidity Test voltage input-output, input-ground DC isolation 500V Output-ground shall not be less than 10MΩ
Fan speed Temperature and Output Current Regulation
Operating temperature -40 +55°C (-40 +135°F)
Temporary storage -40 +70°C (-40 +158°F)
High working height
0~4000 meters, based on 3000 meters,
the temperature drops by 1℃ for every 200 meters above sea level
Storage height
0~4000 meters, based on 3000 meters,
the temperature drops by 1℃ for every 200 meters above sea level
Noise <55dB at nominal input and full load (ambient temperature <30℃)
Cool down Fan (front and rear airflow)
Relative humidity Operation: 5 to 95%RH non-condensing

If you need to download files, you need to register as our member first ! log in / registered

  • EVEREXCEED ER series hot-swappable module embedded rectifier system.pdf
