EBH Pocket Plate Range NiCd Battery

EverExceed pocket type nickel cadmium battery has been supplied stable and reliable battery solution for many industrial power applications. Our block batteries function in a wide range of temperatures, resist electrical abuse, shock and vibrations and need only basic maintenance. This ensures a low total cost of ownership (TCO) over a life cycle that can last 20 years or more.

brand:
EverExceed
Model:
EBH Series
Rated Voltage(V):
1.2V
Rated Capacity(Ah):
10Ah-500Ah
OEM/ODM Service:
Yes, customized
Certificates:
TUV;IEC;ROHS;DEKRA
Usage:
UPS switch transition, railway emergency back-up and start-up power supply

inquiry now

Easy to install and highly durable: NiCd batteries offer excellent resistance to mechanical and electrical abuse, ensuring long-lasting performance in demanding conditions.

Reliable High-Temperature Performance: NiCd batteries maintain stable performance even in high-temperature environments, making them ideal for devices that need to operate under heat stress, ensuring long-term reliability with fewer failures.

①Protective cover
To prevent external short-circuits；

In line with EN50272-2(safety) with ip2 level；

②Plate groups bus
Connects the plate tabs with the terminal post；

Plate tabs and terminal post are projection-welded to the plate groups bus；

③Plate

Horizontal pockets of double-perforated steel stirps；

④Cell container

Material:translucent transparent polypropylene；

⑤Flame-arresting vents

Material: polypropylene；

⑥Plate tab

Spot-welded both to the plate side-frames and to the upper edge of the pocket plate；

⑦Separating grids
These separate the plates and insulate the plate rames from each other；

The grids allow free circulation of electrolyte between the plates；

⑧Plate frame
Seals the plate pockets and serves as a current collector.

Applications:

• Railway DC power supply, UPS switch transition

Cell Type	Nominal Voltage (V)	Capacity (C5 Ah)	Dimensions (mm/inch)						Weight (kg/lb.)				Terminal	Cell Case Material
			Dimensions (mm/inch)						Weight (kg/lb.)
			Length		Width		Height		Without Electrolyte		With Electrolyte
EBH10	1.2	10	55	2.2	134	5.3	270	10.6	1.2	2.6	2.2	4.8	M10	PP
EBH20	1.2	20	55	2.2	134	5.3	270	10.6	1.7	3.7	2.6	5.7	M10	PP
EBH30	1.2	30	70	2.8	140	5.5	295	11.6	2.8	6.2	4.3	9.5	M16	PP
EBH40	1.2	40	80	3.1	140	5.5	365	14.4	4.2	9.3	6	13.2	M16	PP
EBH50	1.2	50	80	3.1	140	5.5	365	14.4	4.5	9.9	6.2	13.7	M16	PP
EBH60	1.2	60	80	3.1	140	5.5	365	14.4	4.8	10.6	6.5	14.3	M16	PP
EBH70	1.2	70	105	4.1	165	6.5	345	13.6	6.8	15	9.2	20.3	M20	PP
EBH80	1.2	80	105	4.1	165	6.5	345	13.6	7.2	15.9	9.6	21.2	M20	PP
EBH90	1.2	90	105	4.1	165	6.5	345	13.6	7.8	17.2	10	22	M20	PP
EBH100	1.2	100	165	6.5	167	6.6	345	13.6	9.2	20.3	13.5	29.8	M20	PP
EBH120	1.2	120	165	6.5	167	6.6	345	13.6	9.8	21.6	14	30.9	M20	PP
EBH150	1.2	150	165	6.5	167	6.6	345	13.6	11	24.2	16	35.3	M20	PP
EBH200	1.2	200	170	6.7	285	11.2	350	13.8	18.5	40.8	26	57.3	2 x M20	ABS
EBH250	1.2	250	170	6.7	285	11.2	350	13.8	20	44.1	27.5	60.6	2 x M20	ABS
EBH300	1.2	300	175	6.9	290	11.4	500	19.7	25	55.1	36	79.3	2 x M20	ABS
EBH350	1.2	350	175	6.9	290	11.4	500	19.7	26	57.3	37	81.5	2 x M20	ABS
EBH400	1.2	400	186	7.3	398	15.7	565	22.2	41	90.4	55	121	3 x M20	ABS
EBH500	1.2	500	187	7.4	399	15.7	566	22.3	43	94.8	57	126	3 x M20	ABS

If you need to download files, you need to register as our member first ! log in / registered

EverExceed NiCd Pocket Plate Range EBH 10-500Ah -V4.0.pdf

Datasheet
