6 in 156cells（630W） PERC half-cut Panel Module

EverExceed 120 cell half cut solar modules are assembled with multi-busbar PERC cells, the half-cell configuration of the modules offers the advantages of higher power output, better temperature-dependent performance, reduced shading effect on the energy generation, lower risk of hot spot, as well as enhanced tolerance for mechanical loading.

brand:
EverExceed
Model:
Monocrystalline
Material:
182x91mm
Maximum Voltage:
1500V
Maximum Power:
630W
Weight:
34Kg

inquiry now

Technical Features


PERC high efficiency 182*91mm solar cells	PID resistant function	Low resistance loss and improved shade tolerance


Higher performance under low light environment	Insured linear 30-year power output guarantee up to 80%，15-year product warranty for materials and processing	Multiwire technology for superior reliability and performance

Product Details

	② Glass • CSG brand, high-strength tempered glass; • Translucency of normal luminance is increased by 2%; • Module efﬁciency is increased by 2%; • Self-cleaning function; • Wind pressure resistance 2400pa; • Snow pressure resistance 5400pa;
① Frame • Strong mechanical load resistance; • Anodic oxidation layer resist to chemical corrosion; • Anodized aluminium alloy frames; • Boost bearing capability and service life;		③ EVA Film • Imported from Japan BRIDGESTONE material, 0.46-0.5mm thick; • Light transmitance more than 92%; • Smail trail prevention treatment; • UV resistance against ageing;
	⑤ Back sheet • Japanese DNP NIPPON material, 0.3-0.35mm thick, poor quality manufacturers use thin PET material, the cost is 50% lower; • Low moisture permeability against snail trail defect; • Outstanding weatherproof performance;
④ Solar Cell • High efﬁciency A grade PV Cells; • The suppliers are ﬁrst-line brands such as MOTECH, JA SOLAR, QCELL Germany, SUNWAYS Germany, etc; • Appearance consistency; • Color sorting ensure consistent appearance on each module; • Anti -PID;		⑥ Junction box • Conventional standalone edition and engineering custom edition; • Quality diodes ensure module's safe operation; • IP67 protection level; • TUV Certiﬁed; • Heat dissipation;

ELECTRICAL CHARACTERISTICS(STC)
Power output (Wp)	630W
Rated Power Maximun Voltage(Vmp)	46.27V
Rated Power Maximun Current(Imp)	13.62A
Open circuit voltage (Voc)	55.86V
Short circuit current (Isc)	14.43A
Module eﬃciency (%)	22.53%
Maximum system voltage (V)	1500V
Maximum series fuse rating (A)	30A
Power output tolerance	0~+5W
FF(%)	78.18%

ELECTRICAL CHARACTERlSTICS WITH REAR SIDE POWER GAIN s
Double side power gain	20%
Max. power output(Pmax)	744W
Rated Power Maximun Voltage(Vmmp)	46.02V
Rated Power Maximun Current(Immp)	16.20A
Open Circuit Voltage(Voc)	56.12V
Short Circuit Current(Isc)	16.96A

LONG-TERM QUALITIY ASSURANCE
First year power degradation	≤1%
Annual degradation	≤0.40%
Linear Power Output Warranty	30 years

CONSTRUCTION
Cells	156cells(6*26)
Cells size	182mm
Junction box	IP68
Diodes	3 by-pass diodes
Glass	2.0 mm highly transparent anti-reﬂection coating tempered glass
Back sheet	2.0 mm highly transparent tempered glass
Frame	Anodized Aluminum Alloy
Weight	34kg
Dimension	2465mm×1134mm×30mm

OTHER CHARACTERISTICS
Operating temperature	-40°C to 85°C
Max. load	5400Pa (front) / 2400 Pa(back)
Fire performance Class C (IEC)	Class C (IEC)
Cable length	TUV/4mm²/-300mm/+300mm
Connector	MC4 compatible

TEMPERATURE CHARACTERISTICS
Isc (α) +0.050% / °C
Voc (β) -0.284% / °C
Pmax (γ) -0.35% / °C
Nominal operating cell temperature 45°C (+/- 2°C)

ELECTRICAL CHARACTERISTICS(NMOT)
Power output (Wp)	474.1W
Max. power voltage (Vmp)	43.60V
Max. power current (Imp)	10.91A
Open circuit voltage (Voc)	53.88V
Short circuit current (Isc)	11.50A

If you need to download files, you need to register as our member first ! log in / registered

ESM-630NTD.pdf
