Telecom lithium battery

UL Approval Energy Storage Lithium Ion 48V 50ah LiFePO4 Battery Pack for Telecom

EverExceed LFP lithium battery telecom solution is mainly used for the backup purpose of telecommunication industry; its performance is in compliance with the requirements in the telecommunication standard, with the adoption of LiFePO4 battery structure packing by flexible plastic film or aluminum alloy rigid packaging, it can satisfy the higher and new requirements of the telecom sector for the communication backup batteries.


  • brand:

    EverExceed
  • Model:

    EV4850-T
  • Rated voltage(V):

    48V
  • Rated capacity(Ah):

    50AH
  • Certificates:

    UN 38.3; UL1642; IEC62133
  • OEM/ODM Service:

    Yes, customized
  • Usage:

    Energy storage system;Solar application;Telecom application;Emergency lighting;Medical equipment
  • Features
  • TECHNICAL DATA
  • SUCCESSFUL CASES
  • Download

UL Approval Energy Storage Lithium Ion 48V 50ah LiFePO4 Battery Pack for Telecom




Key Features









Superior Life Cycles Fast charging Easy replacement



3000+ life cycles, 3-10 times more than traditional lead acid battery Can fully charge within 2-3 hours which is impossible for VRLA
Direct replacement of lead acid battery






More usable capacity Parallel use Easy Implementation



100% of usable energy, can be discharged without causing downtime
The battery supports paralleling of multiple battery packs for increased reserved time
No need to assign extra man power to install


Applications

>Energy storage system  / Solar application / Telecom application / Emergency lighting / Medical equipment




Factory Tour


Adopts electric car-grade battery cells and production technology


Nominal Characteristics
Battery Model EV4850-T(15S) Battery Model EV4850-T(16S)
Nominal Voltage 48 V Nominal Voltage 51.2V
Nominal Capacity 50 Ah Nominal Capacity 50Ah
Nominal Energy 2400 Wh Nominal Energy 2560 Wh
Electrical Characteristics
Recommended Charging Voltage 54-54.7 V Recommended Charging Voltage 57.6-58.4 V
Floating Charging Voltage 51.5-52 V Floating Charging Voltage 55-55.5 V
Recommended Charging Current 25 A Recommended Charging Current 25 A
Maximum Disharging Current 50 A Maximum Disharging Current 50 A
Discharging Cut-off Voltage 40.5 V Discharging Cut-off Voltage 43.2 V
Working Voltage Range 40.5-54.7 V Working Voltage Range 43.2-58.4 V
Operating Conditions
Cycle Life ≥3000 [email protected]% [email protected] Cycle Life ≥3000 [email protected]% [email protected]
Roundtrip Efficiency ≥98% Roundtrip Efficiency ≥98%
Operating Charge Temperature 0℃ to +50℃ Operating Charge Temperature 0℃ to +50℃
Operating Discharge Temperature -20℃ to +60℃ Operating Discharge Temperature -20℃ to +60℃
Storage Temperature -20℃ to +60℃ Storage Temperature -20℃ to +60℃
Mechanical Characteristics
Length x Width x Height 483 x 480 x 133mm Length x Width x Height 483 x 480 x 133 mm
Weight 26.0 Kg Weight 27Kg
Terminal M6 Terminal M6
Optional Function
Remote monitoring
                                                                            SNMP
Anti-theft                                                                   GPS and Gyroscope




If you need to download files, you need to register as our member first ! log in / registered

  • EP-4850-15.pdf
Leave a message
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
