1-24kVA RMI-P Series Inverter for Utility and Telecom (modular type)

EverExceed RMI-P series is a new hot-swappable HF modular inverter with advanced technology and high efficiency. This inverter has been designed to offer low cost per VA and offers our standard features, high level of intelligence, reliability and smart characteristics.The 1/2 19" width modular design made it more flexible, the volume is only half the width of the conventional inverter, saving space and convenient parallel.

brand:
EverExceed
DC Input voltage:
48V DC/ 220V DC
AC Output Voltage:
220VAC
Rated power:
1/2/3 KVA Optional
Rated Output Frequency:
50Hz

inquiry now

Key features


Digital control	N+1 parallel redundant design	High operational reliability	Module built-in bypass
It adopts 32-bit DSP full digital and high-frequency SPWM technology, featuringstrong anti-interference ability, fast calculation speed, high intelligence, accurate control precision and pure output waveform.	It can form an N+1 parallel redundant power supply system. The modules are backup each other, with high reliability and ﬂexible conﬁguration.	The operation and parallel connection of each module are independently controlled by the built-in DSP, no single point of failure, independent ﬂow between modules.	Users can choose inverter priority or bypass priority.

With hot plugging	Smart monitoring	Complete protection	High power density
No need to do any parameter setting and operation，plug and play, the module automatically enters the normal working state, maintenance and replacement is simpleand fast.	Indicator panel, fault sound and light alarm, RS485 communication interface and fault dry contact.	It has the functions of input over-voltage, output over-voltage, over-temperature, short-circuit and so on.	1/2 19〞 width design, the volume is only half the width of the conventional inverter, saving space and convenient parallel.

Product Parameters	Rated Power	1KVA	2KVA	3KVA
	Size （W×H×D）(mm)	9.5"/1U	9.5"/2U
		21644426	21688421
Input Parameter	DC Input Voltage	48VDC/220VDC
	DC Input Range	42～59VDC/190～270VDC
	Bypass Input Range	176～264(Can be adjustable according customer)
	Bypass Switch Time	5～12ms
AC Output	Rate Output Voltage	220VAC
	Rate Output Frequency	50Hz
	Load Regulation	<1%
	Frequency Accuracy	<0.1%
	Crest Ratio	3:1
	Waveform Distortion	Resistance full load＜3%，nonlinear full load＜5%
	Dynamic Response	Voltage transient range＜3%, transient response recovery time≤60ms（load from 0 to 100%）
	Parallel Uneven Flow	＜3% rated current RMS
	Overload Capacity	Load current ＜105%, continuous work
		Load current 105～125%, continuous work 10min shutdown
		Load current 125～150%，continuous work after 1min shutdown
		Load current＞150%，after 20ms shutdown
	Protection Function	Input connection protection, input under voltage and over-voltage protection, output overload protection, output short circuit protection, over temperature protection
Communication	Communication Interface	RS485
Work Environment	Insulation Strength	2kVAC，1min
	Noise (1m)	＜45dB
	Operating Ambient Temperature	－10～50℃
	Transport And Storage Temperature	‘- 40～70℃
	Relative Humidity	0～90%, no condensation
	Relative Altitude (m)	≤3000m，1500～3000m, 1% decrease in output for every 100 m increase

If you need to download files, you need to register as our member first ! log in / registered

RMI-P Series Inverter（1-24KVA）.pdf

Datasheet
