48V 1kWh Power Safe High Quality Deep Cycles LiFePO4 Battery for 5G Telecom Base Tower

EverExceed EV series LiFePO4 adopt high energy density and conversion efficiency of lithium technology in excellent energy-saving performance and longer lifespan. They enables smooth site capacity expansion to support 5G evolution, cutting costs and shortening 5G deployment time. And they are designed with small size, high quality insulation materials and strong anti-theft safety locks. All these advantage make them highly safer, smarter and simpler for telecom 5G micro base station.

brand:
EverExceed
Model:
EV4805-T/ EV4810-T/ EV4820-T
Rated voltage(V):
48V
Rated capacity(Ah):
5-50Ah
OEM/ODM Service:
Yes, customized
Usage:
Base transceiver station, Communication equipments, Telecommunication system.

inquiry now

48V 1kWh Power Safe High Quality Deep Cycles LiFePO4 Battery for 5G Telecom Base Tower

Key Features

Safer:

15+years of design life, longer service life of >3000 cycles.
The highly stable LFP cell removes fire risks if thermal runaway occurs.
Optional heating function and internal insulation design for better environmental adaptability.
The hardest lock to improve energy storage security and prevent stealing.
BMS with internal cell balancing function to ensure the battery is adequately protected.

Smarter:

Intelligent automatic protection for overcharge, over discharge and temperature conditions.
Bluetooth APP control, cuts daily O&M 80% costs by battery management system.
RS485/CAN communication output.
Monitor power supply by connecting APP to avoid the impact of overcharging on battery life.
High power density generates a 70% smaller footprint than lead-acid batteries.

Simpler:

Faster charge, 1 hour of charging can provide up to 90% charge.
No maintenance is required throughout the lifetime.
Small size design make it easier and simpler to install.

Applications

Base transceiver station, Communication equipments, Telecommunication system.

Nominal Characteristics
Battery Model	EV4805-T	EV4810-T	EV4820-T
Nominal Voltage	48 V	48 V	48 V
Nominal Capacity	5 Ah	10 Ah	20 Ah
Nominal Energy	240 Wh	480 Wh	960 Wh
Electrical Characteristics
Recommended Charging Voltage	53.5 V
Floating Charging Voltage	52.5 V
Recommended Charging Current	2.5 A	5 A	10 A
Maximum Charging Current	5 A	10 A	20 A
Maximum Discharging Current	15 A	30 A	60 Ah
Discharging Cut-off Voltage	42 V	42 V	42 V
Working Voltage Range	42-54 V	42-54 V	42-54 V
Operating Conditions
Cycle Life	≥3000 Cycles@100% DOD@25°C	≥3000 Cycles@100% DOD@25°C	≥3000 Cycles@100% DOD@25°C
Roundtrip Efficiency	≥98%	≥98%	≥98%
Operating Charge Temperature	0℃ to +50℃	0℃ to +50℃	0℃ to +50℃
Operating Discharge Temperature	-20℃ to +60℃	-20℃ to +60℃	-20℃ to +60℃
Storage Temperature	-20℃ to +60℃	-20℃ to +60℃	-20℃ to +60℃
Mechanical Characteristics
Length x Width x Height	380 x 220 x 145 mm	380 x 220 x 145 mm	430 x 320 x 150 mm
Weight	8.0 Kg	10 Kg	15 Kg
Terminal	M4	M4	M6
IPGrade	IP 55
Optional Function
Remote monitoring	Bluetooth
Others	Heating

If you need to download files, you need to register as our member first ! log in / registered

Telecom Lithium Iron Phosphate (LiFePO4) Battery EV4820-T V 2.3 20250421.pdf


Datasheet

1. What type of battery does EverExceed provide for 5G telecom applications?
EverExceed offers high-performance wall-mounted LiFePO₄ (Lithium Iron Phosphate) batteries specifically designed for 5G telecom base stations, featuring compact size, high energy density, and superior safety.

2. What is the service life of EverExceed’s 5G wall-mounted batteries?
Our batteries typically last over 15 years, with more than 3000 charge/discharge cycles at 80% depth of discharge (DoD).

3. Are EverExceed wall-mounted batteries suitable for outdoor or harsh environments?
Yes. The battery housing is designed with high IP protection levels (e.g., IP55/IP65) and robust mechanical design to withstand outdoor conditions such as heat, humidity, and dust.

4. What voltage and capacity options are available?
EverExceed offers a range of models from 48V 5Ah - 20Ah (or custom), which can be paralleled to meet specific backup time and load requirements of different 5G sites.

5. Are the batteries compatible with existing telecom power systems?
Yes. EverExceed batteries support standard telecom voltage (48VDC) and feature multiple communication interfaces like RS485, CAN, and SNMP, ensuring seamless integration with most rectifiers and monitoring systems.

6. How is battery health and safety monitored?
The built-in BMS (Battery Management System) constantly monitors voltage, current, temperature, SOC, and SOH to ensure reliable and safe operation, while offering alarms and protections in real-time.

7. Is remote monitoring supported?
Yes. With SNMP or Modbus over RS485/CAN, our batteries can be connected to network monitoring platforms for remote diagnostics and maintenance.
