Solar Energy Storage

Lithium Solar Battery 48V100ah Rechargeable Battery Pack / Deep Cycle LiFePO4 Batteries

EverExceed LiFePO4 batteries are perfect choice for your home energy storage system and SME (Small Medium Enterprise). The ultra-modern design brought to you by our highly qualified research and development team provides an ultra long service life and extreme reliability in energy storage. Based on our batteries technical features of excellent performance on higher temperature, higher capacity range, lighter weight and pollution free operation, our LiFePO4 battery is widely popular by users with a rapid development stance. It is the first choice for the high requirement energy storage battery solution.



  • brand:

    EverExceed
  • Model:

    EP-48100
  • Rated voltage(V):

    48V
  • Rated capacity(Ah):

    100AH
  • Certificates:

    UN 38.3; UL1642; IEC62133
  • OEM/ODM Service:

    Yes, customized
  • Usage:

    Solar energy storage; wind energy storage
  • Features
  • TECHNICAL DATA
  • SUCCESSFUL CASES
  • Download
  • Related documents
  • Video
  • FAQ

Lithium-Solar-Battery 48V100ah Rechargeable-Battery-Pack/Deep-Cycle-LiFePO4 Batteries



Key Features






High cycle life and deep cycle ability High reliability


High cycle times and longer service life of >6000 cycles
@80% DOD ;
Superior DOD (100% over lead acid bateries;
Excellent high temperature performance, ultra low life
decay rate in operating when harsh environment;
Ultra low self discharge rate <1.5%/month;




More usable capacity User friendly bms user


LFP provides 100% of usable energy, so that you can discharge
the battery entirely without causing downtime of your solar site,
saving cost of diesel generator fuel.
User friendly BMS monitors and communicates regarding the
SOC, SOH, protects the system from short-circuit, high and low
discharging and charging, high temperature etc.




Faster charging Easy install ation


Charges much faster than sealed lead acid batteries, giving you
access to reliable power quicker to continue your operation.
Can fully charge within 2-3 hours which is impossible for VRLA.
EverExceed LFP batteries are designed to be drop-in replacement
for sealed lead acid batteries without additional labor cost.




High discharge rate Superior deep cycling ability


Ability to deeply discharge the battery at a high rate of discharge
while maintaining a high energy capacity.
Excellent PSOC (partial stage of charge) cycle life, which is the best ideal choice for solar energy storage;
Optimized for photovoltaic applications, using high temperature and high cycle life active materials;


Advantages


● Optimized for photovoltaic applications, using high temperature and high cycle life active materials;
● Increased energy in given space;
● Parallel connection available for flexible system capacity extension;
● High operational reliability;
● Optimized supervision strategy through remote control/diagnostic;

● Very long life time;
● Preventive but not premature replacement at end of life;
● Maintenance free throughout lifetime;
● Compatible with most of the available hybrid inverters;
● Compact and fashionable design fits in your sweet home environment;
● Conforms to safety standards of IEC62133, CE, UN38.3;


Applications

>Solar energy storage / Wind energy storage;



Factory Tour


Adopts electric car-grade battery cells and production technology


Nominal Characteristics
Battery Model EP-48100
Nominal Voltage 48V 51.2V
Nominal Capacity 100 Ah 100Ah
Nominal Energy 4800 Wh 5120 Wh
Electrical Characteristics
Recommended Charging Voltage 54 ± 0.5 V 57.6 ± 0.5 V
Recommended Charging Current 30A 30A
Maximum Discharging Current 100 A 100 A
Operating Conditions
Cycle Life ≥6000 Cycles@80% DOD@25
Round-trip Efficiency ≥98%
Operating Charge Temperature 0 to +50
Operating Discharge Temperature -20 to +60
Storage Temperature -20 to +60
Mechanical Characteristics
Length x Width x Height 483 x 480 x 155 mm
Weight 43 Kg 45.5 Kg
Terminal M6
IP Rating IP20








If you need to download files, you need to register as our member first ! log in / registered

  • EP-48100 (15S) V2.1 20240229.pdf
