Solar Energy Storage

Lithium-Solar-Battery 48V200ah Rechargeable-Battery-Pack/Deep-Cycle-LiFePO4 Batteries

EverExceed LiFePO4 batteries are perfect choice for your home energy storage system and SME (Small Medium Enterprise). The ultra-modern design brought to you by our highly qualified research and development team provides an ultra long service life and extreme reliability in energy storage. Based on our batteries technical features of excellent performance on higher temperature, higher capacity range, lighter weight and pollution free operation, our LiFePO4 battery is widely popular by users with a rapid development stance. It is the first choice for the high requirement energy storage battery solution.



  • brand:

    EverExceed
  • Model:

    EP-48200
  • Rated voltage(V):

    48V
  • Rated capacity(Ah):

    200AH
  • Certificates:

    UN 38.3; UL1642; IEC62133
  • OEM/ODM Service:

    Yes, customized
  • Usage:

    Solar energy storage; wind energy storage
  • Features
  • TECHNICAL DATA
  • SUCCESSFUL CASES
  • Download

Lithium-Solar-Battery 48V200ah Rechargeable-Battery-Pack/Deep-Cycle-LiFePO4 Batteries



Key Features






High cycle life and deep cycle ability High reliability


High cycle times and longer service life of >6000 cycles
@80% DOD ;
Superior DOD (100% over lead acid bateres;
Excellent high temperature performance, ultra low life
decay rate in operating when harsh environment;
Ultra low self discharge rate <1.5%/month;




More usable capacity User friendly bms user


LFP provides 100% of usable energy, so that you can discharge
the battery entirely without causing downtime of your solar site,
saving cost of diesel generator fuel.
User friendly BMS monitors and communicates regarding the
SOC, SOH, protects the system from short-circuit, high and low
discharging and charging, high temperature etc.




Faster charging Easy install ation


Charges much faster than sealed lead acid batteries, giving you
access to reliable power quicker to continue your operation.
Can fully charge within 2-3 hours which is impossible for VRLA.
EverExceed LFP batteries are designed to be drop-in replacement
for sealed lead acid batteries without additional labor cost.




High discharge rate Superior deep cycling ability


Ability to deeply discharge the battery at a high rate of discharge
while maintaining a high energy capacity.
Excellent PSOC (partial stage of charge) cycle life, which
is the best ideal choice for solar energy storage;
Optimized for photovoltaic applications, using high
temperature and high cycle life active materials;


Advantages


● Optimized for photovoltaic applications, using high temperature and high cycle life active materials;
● Increased energy in given space;
● Parallel connection available for flexible system capacity extension;
● High operational reliability;
● Optimized supervision strategy through remote control/diagnostic;

● Very long life time;
● Preventive but not premature replacement at end of life;
● Maintenance free throughout lifetime;
● Compatible with most of the available hybrid inverters;
● Compact and fashionable design fits in your sweet home environment;
● Conforms to safety standards of IEC62133, CE, UN38.3;


Applications

>Solar energy storage / Wind energy storage;



Factory Tour


Adopts electric car-grade battery cells and production technology



Battery Type LiFePO4 (Lithium iron phosphate battery)
Battery Model EP-48200
No.Of Cells In Series 15 16
Norminal Voltage 48V 51.2V
Norminal Capacity 200Ah
Norminal Energy 9.6KWh 10.24KWh
Dimension (H x W x D) 483*620*177mm
Weight 80kg 85kg
Boost Charge Voltage (Charging Method: CC-CV) 54V-54.75V 57.6-58.4V
Float Charge Voltage 52V 55.2V
Discharge Cut-off Voltage 40.5V 43.2V
Recommended Charge Current 50-100A
Max Discharge Current 100A
Working Temperature Range
Discharge: -20℃ to +60℃
Charge: 0℃ to +45℃ Storage: -20℃ to +60℃
Cycle Life ≥6000 cycle @ 80%DOD @ 25 @ 0.5C rate
Communication RS485 / RS232 / CAN
Compatible Inverter* SMA, SolarEdge, Sungrow, Huawei, Victron Energy, Schneider, Growatt, EverExceed, Ginlong, Sofarsolar, SolaX, East, Deye, etc.*
Safety Standard IEC62133, CE, UN38.3
Design Life 15+Years @ 25℃





If you need to download files, you need to register as our member first ! log in / registered

  • EverExceed 48V Modular Solar Lithium Battery - Rack mounting v17(2021-07-21).pdf
