Energy storage

EverGen VRLA Energy Storage Solution

If you are looking for a backup power solution for your apartment, home, small office, clinic, restaurant etc. applications, where the grid connection is not stable and reliable, then EverExceed EverGen Series has the best Backup energy storage solution to solve all of your problems. It is a perfect replacement for your portable generator to eradicate the fuel cost, noise pollution and environment pollution with smoke and bad smell effectively.
  • brand:

    EverExceed
  • Model:

    EG
  • Inverter Power:

    24/48VDC
  • Application:

    Home, apartment or villa; Shops and groceries for small business; School or baby care center; Small office or enterprise; Bank, ATM or financial institute; Clinic, health care or medical centers;
  • Features
  • TECHNICAL DATA
  • SUCCESSFUL CASES
  • Download


Technical Features




Long backup time with minimum switching time High quality transformer inverter Green energy
This solution can provide you with long backup time, can be discharged up to 100% capacity without damaging the battery. The less than 20ms switching time ensures uninterruptible operation of your computer, TV or any other appliance.
This solution is consist of high quality transformer inverter, ensuring the complete reliability even in worst grid performance. Best solution for places with regular hurricane, storm affected weather, and poor grid connection where cheap inverter will fail easily.
This solution has absolutely no effect on the environment, completely green energy. No loud noises, no smoke or fume, no fuel smell, no toxic gas release, no acid splash. The outlook is beautiful and clean. The system is small and mobile, can be customized as per the requirement of customer.




Operational diagram




EverExceed Front Access VRLA Battery


◆12+ years of design life;
◆EverExceed's special advanced long deep cycle life technology,≥50% service life increased;
◆Best in the market 99.994% pure lead used in every single battery; .
◆Advanced lead high-tin low-calcium alloy, reduces grid corrosion and promotes long battery life;
◆Optimized high-compression Absorbed Glass Mat (AGM)
materials significantly enhance performance and reliability, greater than 99% recombination efficiency;
◆Advanced triple stage unique terminal sealing design to ensure leak free operation;
◆Designed to withstand extreme temperature degrees and performance without degradation;
◆Flame arresting, low pressure safety release venting system for individual cells, recognized per U.L.924,
◆Have the professional certification of UL1989,CE, IEC 60896;



High quality transformer inverter

•  High quality copper wire transformer.
•  Confirms reliability with supreme switching time of less than 20ms, absolutely no interruption in your computer, tv, refrigerator etc. application
•  Provides precise service during the most disturbing grid performance.
•  Not available in cheap energy storage system.



Application

Home, apartment or villa;   Shops and groceries for small business;   School or baby care center;

Small office or enterprise;   Bank, ATM or financial institute;    Clinic, health care or medical centers







Model EG3K-5E EG6K-10E EG8K-15E EG10K-20E
System Specification
Rated AC Output Power 3000W 6000W 8000W 10000W
Surge AC Output Power 6000W 12000W 16000W 20000W
Energy Capacity Range 4.8kWh 9.6kWh 14.4kWh 19.2kWh
Battery Type Deep Cycle Lead Acid Battery
Output Overload Capacity
105%<Load<120%(10 seconds)
120%<Load<150%(3 seconds)
Load150%(1 seconds)
Operating Temperature -20 to 50
Storage Temperature -30 to 60
Humidity 0~95%(no condensation)
Altitude 0~2000m
Noise 50dB
IP Protection IP21
Dimensions W 650mm 650mm 650mm  650mm
D 400mm 400mm 500mm 500mm
H 800mm 1080mm 1780mm 1780mm
Inverter Specification
Rated AC Output Power 3000W 6000W 8000W 10000W
Rated Battery Voltage 24VDC 48VDC 48VDC 48VDC
AC Input Voltage 155Vac~275Vac90Vac~154Vac optional
AC Output Voltage 220/230/240Vac(100/110/120Vac optinal)
Rated Frequency 50/60Hz
Max. Charging Current 50A 50A 70A 85A
Power Factor 1.0
Output Wave Form Pure Sine Wave
Transfer Time <15ms
Battery Specification
Battery Model FT12V200 FT12V200 FT12V150 FT12V200
Norminal Capacity 200Ah 200Ah 150Ah 200Ah
Battery Voltage 24V 48V 48V 48V
Battery Quantity 2 4 8 8
Energy Capacity 4.8kWh 9.6kWh 14.4kWh 19.2kWh
Cycle Life 800 [email protected]% DOD


If you need to download files, you need to register as our member first ! log in / registered

  • LV version - EverGEN Solar VRLA Series ESS V1.2 2022.06.17.pdf
